Kit Sigfox Access Station Micro SMBS-T4 + Accessories

As low as €570.00 €475.00

Sigfox gateway to add coverage where you need it, easaly!
Station configured RC1 (EMEA)
Terms & Conditions of Use

In stock

SKU

PB0002850

Details

The Sigfox Access Station Micro provides affordable IoT service coverage

to thousands of Sigfox devices

It targets operator densification and customer premises as an extension of the public network in areas such as deep indoor or remote locations.

Coverage… Where you need it

Discreet with integrated antenna and sleek design, Sigfox Access Station Micro can be installed anywhere: hidden or on display, indoor or outdoor, in an attic or underground, in warehouses, buildings, shops, farms or offices…With the sealing cover, the Access Station Micro is dust and water resistant (IP65).

Coverage… Made easy

With its compact form factor and integrated antenna, Sigfox Access Station Micro can be easily installed within minutes. Accessories are included in the box to start using the Access Station Micro straight away.

Power-over-Ethernet allows flexible installation and do not necessarily require professional assistance.

The Access Station Micro connects to Sigfox Cloud via existing LAN infrastructure and Internet access, but it also has the possibility to use cellular networks for quick and versatile installations.

Coverage… Affordable

Sigfox Access Station Micro addresses the challenges of affordable coverage densification by keeping the RoI of your IoT solution deployment and operations low.

Designed with great sensitivity it can cover an entire building⁽¹⁾ and can process up to 70 000 frames per day⁽²⁾.

With extremely low energy consumption, the Access Station Micro is compatible with smart solar panel deployment enabling untapped application connectivity where no power source is available.

⁽¹⁾Subject to building materials and any obstructions or interference present
⁽²⁾Subject to available bandwidth and installation guidelines

• The Sigfox network allows to send up to 140 messages per day of 12 bytes long.

• The Sigfox network is available in many European countries.

• Please check available coverage on

Questions and Answers :

• What type of connectivity does Sigfox Access Station Micro use?

The station uses Internet connectivity, and can also connect via a compatible 3G or 4G dongle for alternative or backup cellular connectivity.

• Does it support PoE (Power over Ethernet) functionality?

Yes, the Sigfox Access Station Micro supports PoE functionality, enabling convenient power supply via an Ethernet cable.

• What is the recommended method of protecting the station externally?

For outdoor installation, we recommend using the waterproof cover and ensuring that the station is protected against weather and temperature variations.

• What tools are available for configuring and monitoring the Sigfox station?

The tools available include the Access Station Utility application for local pre-commissioning and configuration, and the SIGFOX backend interface for remote monitoring and management.

• What is the exact model of the Sigfox Access Station Micro listed on our site?

The exact model listed is the SMBS-T4.

Installation :

To use your Access Station Micro, you will need:

• Internet connection: either by Ethernet port or compatible 3G/4G USB dongle⁽³⁾
• Indoor 220 / 110 V AC power outlet
• Android phone or tabelle to modify the station network configuration

To install the Access station micro outside, or in an environment exposed to high humidity, dust, or even to prevent thief, you must use the sealing cover to protect the connectors and the USB dongle if used.
The sealing cover provides an Ingress Protection IP65.

⁽³⁾Only compatible 3G / 4G USB dongle can be used, available in option

Technical specifications:

• RADIO CHARACTERISTICS

Standard	Sigfox Ultra Narrow Band Protocol for M2M and IoT
Max range of operating frequencies*	865 to 928 MHz
Max Receiver Sensitivity	-132dBm @ 100bps / -124dBm @ 600bps
Data Rate and Modulation	100 / 600 bps D-BPSK (UL), 600 bps GFSK (DL), OOK (Monarch beacon)
Max Transmit Power (EIRP)*	23 dBm ± 1dB
Antenna	Integrated

• INTERFACES

Ethernet	1 x RJ45 (10/100BaseT)
USB port	1 x USB 2.0 female type A

• POWER

Power Consumption	2.3W typical (Rx mode, Ethernet) / 7.5W max peak **
Power supply	Passive PoE with AC 220/110V adaptor in package
Input DC voltage	11 to 26V

• MECHANICAL AND ENVIRONMENTAL

Casing dimensions (W, H, D)	186 x 159 x 108 mm (7.3 x 6.3 x 4.25 in)
Product weight	450 g (1 lb)
Packaging weight and dimensions	1.3 kg 243 x 280 x 147 mm
Operating temperatures	-20°C to +55°C (-4°F to 131°F)
Storage temperatures	-30°C to +85°C (-22°F to 185°F)
Robustness	MTBF 92,000 hours
Protection	IP65 (with sealing cover)
Casing material	Plastic ASA/PC

• COMPLIANCE

Safety	EN 60950-1, IEC 60950-1 ; EN 62368-1, IEC 62368-1
Radio	EN 300 220-2 ; EN 300 220-1 ; FCC part 15.247 ; ARIB STD-T108
EMC	EN 301 489-3 ; EN 301 489-1 FCC Part 15 B ; FCC 15.207 and FCC 15.209

(*) The maximum frequency range and power setting will vary by channel and according to country regulations. Refer to the regulatory groups table for more details
(**) Cellular dongle increases peak power consumption and is model dependant (5W max)

Package contents:

• Sigfox Access Station Micro SBMS-T4
• Mounting kits (2 ties and 2 set of screws and anchors)
• PoE DC injector
• Ethernet cable CAT6 1.5m
• Power adaptor 110/220V AC to 24V DC 18W
• Quick Start Guide / Safety Notice
