Raspberry Pi 3 Model B+ 1Gb

  Board Raspberry Pi 3 Modèle B+ 1Gb

Improved performance: Enabling the core processor to operate faster. Speed 1.4Ghz Increased connection speed and bandwidth: Dual band Wireless connectivity 802.11AC (2.4GHz / 5.0GHz) Faster network data transfer: New Ethernet controller (~300MBPS) Simpler & more effective installation/distribution: Power over Ethernet (PoE HAT in option)

The Raspberry Pi 3 Model B+ is the latest product in the Raspberry Pi 3 range, boasting a 64-bit quad core processor running at 1.4GHz, dual-band 2.4GHz and 5GHz wireless LAN, Bluetooth 4.2/BLE, faster Ethernet, and PoE capability via a separate PoE HAT.

The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market.

The Raspberry Pi 3 Model B+ maintains the same mechanical footprint as both the Raspberry Pi 2 Model B and the Raspberry Pi 3 Model B.

Warning:

Check that your system installed on your micro SD card supports the Pi 3 B + version https://www.raspberrypi.org/learning/software-guide/
When installing it if only the red LED lights up, check https://www.raspberrypi.org/learning/troubleshooting-guide/red-light/

Technical improuvements:

• Improved power performance
• Enabling the core processor to operate faster. Speed 1.4Ghz

• Dual band Wireless connectivity 802.11AC (2.4GHz / 5.0GHz)
• Increased connection speed and bandwidth
• Greater range when connected to the 5GHz channel
• Backward compatibility within applications
• Improved streaming HD video over WIFI
• Increased effectiveness as a wireless access point

• New Ethernet controller
• 3 X Ethernet speed of the current Raspberry Pi3 Model B (~300MBPS)

• Power over Ethernet (PoE) enabled
• PoE operation requires the purchase of the new PoE HAT which will be available at launch.
• Without being tethered to an electrical outlet, the Raspberry Pi 3B+ can be located wherever it is needed most, and repositioned easily if required up to a range of 100m.
• Having power available over a network means that installation and distribution of network of Raspberry Pi’s becomes simpler and more effective

Technical Specifications:

• Processor:
• Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4GHz
• Memory:
• 1GB LPDDR2 SDRAM
• Connectivity:
• 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN
• Bluetooth 4.2, BLE
• Gigabit Ethernet over USB 2.0 (maximum throughput 300Mbps)
• 4 × USB 2.0 ports
• Access:
• Extended 40-pin GPIO header
• Video & Sound:
• 1 full size HDMI
• MIPI DSI display port
• MIPI CSI camera port
• 4 pole stereo output and composite video port
• Multimedia:
• H.264, MPEG-4 decode (1080p30); H.264 encode (1080p30); OpenGL ES 1.1, 2.0 graphics
• SD card support:
• Micro SD format for loading operating system and data storage
• Input power:
• 5V/2.5A DC via micro USB connector
• 5V DC via GPIO header
• Power over Ethernet (PoE)–enabled (requires separate PoE HAT)
• Environment:
• Operating temperature: 0–50°C
• Compliance:
• For a full list of local and regional product approvals, please visit www.raspberrypi.org/products/raspberry-pi-3-model-b+
